Description

Features

1. 32bit/768kHz decoding, and DSD256.

2. Using dual CS43198 decoding chips, improving the performance of digital-to-analog conversion.

3. The balanced port output of up to 4Vrms.

4. The dynamic range as high as 131db, combined with ultra-low total harmonic distortion as low as 0.0001% and high performance SINAD as high as 116db, offering an ultra-high performance.

5. SNR is as high as 113db, the background noise is Inaudible even for the ultra-high sensitivity headphones.

6. 3.5 Single-ended output +4.4 balanced output.

7. The name of post-modernism steampunk industrial design explains well to its design elements.

8. CNC precision machining of lightweight aviation aluminum alloy shell, has excellent anti-interference performance.

Specification

[MOONRIVER2] MINI Portable DAC/AMP
Weight: 17.1g
Size: 56.8mm x 19.4mm x 12.5mm
Earphone Jack:
3.5mm Single-ended
4.4mm Balanced
Frequency response range: 6Hz-85kHz (±1dB)
Background Noise:
4.4mm: 1.5μV(AES17 20kHz)
3.5mm: 1.2uV(AES17 20kHz)
SNR:
3.5mm: 123dB(A weighted)
4.4mm: 131dB(A weighted)
Line output:
3.5mm: 2Vrms(High), 1.4Vrms(Low)
4.4mm: 4Vrms(High), 2.8Vrms(Low)

Package

1. [MOONRIVER2] USB DAC/AMP * 1
2. Type-C to Type-C adapter * 1
3. Type-C to Type-A adapter * 1
4. Certificate * 1
5. Manual * 1
6. Warranty Card * 1

Download

MOONDROP USB Audio Driver WHQL Download

MOONDROP Link APP Download
