This is a earbud designed to reproduce real timbre, powerful details and dynamics. It combines cutting edge materials and structure design and actualized outstanding preformance that previously impossible to achieve. Infuse natural tone of musical instruments, treble response and bass punch all into one package. Wide, natural soundstage, lifelike, analytical resolution and accurate, smooth imaging, previously unreachable characteristics for earbuds. Liebesleid elucidate our persue of ideal earbud performance. True sound is all it has to deliver.
Liebesleid's faceplate is also carved from whole piece of brass, the venting on top of it is precisely calculated and manufactured in same accuracy to ensure the ultra high frequencies are preserved.
Liebesleid's back chamber has a sophiscated structure after several trial production and redesign. This structure suepress the standing wave inside chamber into a subtle equilibrium which improves soundstage while not introduce distortion. Reproducing space and timbre in an ideal way.
This high performance dynamic driver specifically for Liebesleid took us and our cooporating firm one and a half year to develop. Combining outer magnet structure which is rarely seen on earbuds with N52 magnet makes transducer of Lievesleid to provide a magnetic flux density of 1.2Tesla. This high flux density and long coil design make the transducer to have a outstanding large linear stroke. Wrinkle less hybrid diaphragm and lightweight coil forms a very flexible suspension system. These design allow Liebesleid to have a ultra wideband that won't attenuate at 20khz, and attenuate less than 35dB at 35kHz, analytical that feels nothing lost, fast transients and powerful dynamic.
The very core of Liebesleid's transducer is this exquisite diaphragm. It forms a suspension system commonly found in speakers but rare in earbuds: dome, cone and surround. The high rigidity polymer used on dome and cone provide aboundant mid-high-ultrahigh frequency details and extension with little distortion. Soft, high damping coefficient surround part give it high stroke, fast attenuation, ample dynamic on all frequencies, high sound intensity, outstanding mid-low frequency details and transients.
* This frequency response is measured with a ear simulator and taking account of HRTF.
measured with a ear simulator and taking account of HRTF.
On the exhaustive process of tuning Liebesleid, we simulate true human ear with refrence to Head Related Transfer Function to reproduce lifelike accurate timbre and natural, well rounded soundstage.
OFC cable with a silver plating of 8um gives almost linear impedance at musical frequencies ensures high fidelity of signals reaching the driver units.
Inheriting a product tradition, Liebesleid also has this carved ring on its left channel, but easier to identify. this also contributes to subtle element of its aesthetics.
Every set of Liebesleid is made from dustless workshop in our headquarter. Systematic manufacturing management, lab level manufacturing devices and craftsmanship. We prefer quality over efficiency to ensure every liebesleid has same excellent performance.
Building
Driver: Dynamic Driver
Driver diameter: 13.5mm
Cavity Diameter: 15.8mm
Frequency response: 10Hz-45kHz
Effective frequency response: 20Hz-20kHz
Impedance: 24Ω (±15%)
THD: ≤0.5%@1kHz
Difference between left and right unit: ≤1dB
Material: brass chrome-plating
Cable: 8μm silver-plated 4N OFC
Cable length: 1.2m
Driver magnet: N52 annular external magnet
Magnet Density: > 1 Tesla
Driver features: long-stroke coil
Diaphragm: Special composite non-textured diaphragm
Jack: 3.5mm gold-plated
(It's recommended to burn-in more than 200hours)
